The RAX 7020 is a high-performance and cost-effective power amplifiers designed to deliver high power, rock-solid stability, and superb acoustic characteristics.
| Power Output | heading |
|---|---|
| 2 Ω (True RMS),20Hz-20kHz,1% THD | 2 x 3500 W |
| 2 Ω (EIA), 1kHz , 1%THD | 2 x 4500 W |
| 4 Ω (True RMS),20Hz-20kHz,1% THD | 2 x 2400 W |
| 4 Ω (EIA), 1kHz , 1%THD | 2 x 3100 W |
| 8 Ω (True RMS),20Hz-20kHz,1% THD | 2 x 1400 W |
| 8 Ω (EIA), 1kHz , 1%THD | 2 x 1800 W |
| Bridged Mode | heading |
| 4 Ω (True RMS),20Hz-20kHz,1% THD_ | 7000 W |
| 8 Ω (T rue RMS),20Hz-20kHz,1% THD | 4800 W |
| Damping factor (8 Ω) | > 350:1 |
| Frequency Range | 20Hz-20kHz (± 0.5dB) |
| Protection | Temperature, DC, Short Circuit, Soft-Start |
| Input Connector (Per Channel) | XLR, jack stereo 6.3mm |
| Output Connector (Per Channel) | Speakon and Binding Post |
| Dimensions (W x D x H) mm | 482 x 527 x 133 (3U) |
| Net Weight (Kg) | 34 |
| Series | RAX Series |
| /wp-content/uploads/manuals/RAX_Series_Manual.pdf |
The RAX 7020 is an SM Professional PA product in the RAX Series. Available from Mansukhlal Sales Corp, an authorized dealer.
Rugged & Reliable Professional Stereo Power Amplifier; Built-in crossover and bass boost switch; High-current toroidal transformers with high-endurance cores for a wide transient response; Audio-grade rectifier capacitors for superior sonic performance; High-quality double-sided PTH PCBs and components ensure reliability even in tough ambient environs; 3 switchable operational modes: stereo, parallel, and bridge.
The RAX 7020 power output is heading.
The RAX 7020 2 ω (true rms),20hz-20khz,1% thd is 2 x 3500 W.
The RAX 7020 2 ω (eia), 1khz , 1%thd is 2 x 4500 W.
The RAX 7020 4 ω (true rms),20hz-20khz,1% thd is 2 x 2400 W.
The RAX 7020 4 ω (eia), 1khz , 1%thd is 2 x 3100 W.
