SM Professional
The X 35 is a 4 channel DJ mixer with a built-in USB MP3 media player & Bluetooth, 3-band kill EQ (-30 dB) and a wide variety of inputs and outputs to let you mix in style.
| Series | X Series |
|---|---|
| Gain (Mic / Phono / Line) | 40dB / 40dB / 0dB |
| Input Level Sensitivity (Mic / Phono / Line) | -40dBu / -40dBu / 0dBu |
| Main Output level (Nominal / Max) | 0dBu (0.775V) /+18dBu (6.15V RMS) |
| Booth Output Levels (Nominal/Max) | 0dBu(0.775V) Nominal/ +18dBu(6.15V RMS) Max |
| Frequency Response | 20Hz-22KHz (+/-3dB) |
| Total Harmonic Distortion | 0.07% @ 1KHz 0.1% @ 1KHz |
| Equalisation Line I/P (Treble/Mid/Bass) | +10/-12 dB @ 10KHz , +12/-24dB @ 1.3KHz, +12/-29dB @ 50Hz |
| Signal to Noise Ratio (Mic/Line) | 60dB / 82dB |
| Dimension (W x D X H) mm | 242 x 104 x 294 |
| Net Weight | 2.4 Kg |
| /wp-content/uploads/manuals/X35_Instruction_Manual.pdf |
The X 35 is an SM Professional PA product in the X Series DJ. Available from Mansukhlal Sales Corp, an authorized dealer.
3-band kill EQ (-30 dB) and gain control per channel; Balanced XLR mic input with gain and 2-band EQ; Built-in USB MP3 media player with wireless Bluetooth connectivity; Crossfader reverse / normal / flat / steep curve switch; Headphone cue Mix with blend switch; Separate master, record and booth RCA output.
The X 35 gain (mic / phono / line) is 40dB / 40dB / 0dB.
The X 35 input level sensitivity (mic / phono / line) is -40dBu / -40dBu / 0dBu.
The X 35 main output level (nominal / max) is 0dBu (0.775V) /+18dBu (6.15V RMS).
The X 35 booth output levels (nominal/max) is 0dBu(0.775V) Nominal/ +18dBu(6.15V RMS) Max.
The X 35 frequency response is 20Hz-22KHz (+/-3dB).
