Ahuja
VX-400
- Power
- 400 WATTS
- Series
- VX Series
- Category
- Speakers
- Category
- Passive Speakers
The Ahuja VX-400 is a 400W moulded cabinet speaker system with 15" LF woofer and dynamic horn. It has a rugged and portable bass reflex cabinet moulded with a special polypropylene plastic material.
It has special cabinet profile allows functional flexibility in various professional audio applications such as stage monitors, live sound reinforcement and installed sound systems.
Features
- High quality 400W, 2-Way PA speaker system comprises of a high performance 38.1cm (15") LF speaker and a reliable HF driver. Ideal for use in a wide variety of speech & music applications.
- Rugged & portable bass reflex cabinet moulded with a special polypropylene plastic material.
- Built with a 38.1cm (15") 400W reliable & efficient LF speaker.
- High performance HF driver made with a 4.44cm (1.75") voice coil & titanium diaphragm.
- Equipped with a professional passive crossover network using low resistance inductors & high quality metallised polyester capacitors.
- Special cabinet profile allows functional flexibility in various professional audio applications such as stage monitors, live sound reinforcement and installed sound systems.
- A pole socket is provided at the bottom for easy stand mounting as well as wall mounting.
- Three integrated M8 flying points on top side and right side of the cabinet enable vertical and horizontal suspension applications.
Specifications, Q&A and videos
| Power Rating | 400W RMS/800W Programme |
|---|---|
| Configuration | Two Way |
| Frequency Response | 45-18,000Hz |
| Low Frequency Speaker | 1 x 381mm (15”), Ø76.2mm (3.0”) Copper Voice Coil |
| High Frequency Unit | Dynamic Horn, Ø44.45nn (1.75”) Voice Coil |
| SPL at (1W/1m) | 98dB |
| Max. Rated SPL | 124dB |
| Nominal impedance | 8Ω |
| Port | Free Flow Flared |
| Input Connectors | 2 Nos. of Speakon Sockets |
| Dimensions | W460 × H690 × D370 mm |
| Weight | 22.10kg |
The VX-400 is an Ahuja moulded cabinet speaker system in the VX Series. The Ahuja VX-400 is a 400W moulded cabinet speaker system with 15" LF woofer and dynamic horn. Authorized Ahuja dealer for Maharashtra and Goa — enquire at Mansukhlal Sales Corporation for specification and quotes.
High quality 400W, 2-Way PA speaker system comprises of a high performance 38.1cm (15") LF speaker and a reliable HF driver. Ideal for use in a wide variety of speech & music applications; Rugged & portable bass reflex cabinet moulded with a special polypropylene plastic material; Built with a 38.1cm (15") 400W reliable & efficient LF speaker; High performance HF driver made with a 4.44cm (1.75") voice coil & titanium diaphragm; Equipped with a professional passive crossover network using low resistance inductors & high quality metallised polyester capacitors; Special cabinet profile allows functional flexibility in various professional audio applications such as stage monitors, live sound reinforcement and installed sound systems.
The VX-400 configuration is Two Way.
The VX-400 frequency response is 45-18,000Hz.
The VX-400 low frequency speaker is 1 x 381mm (15”), Ø76.2mm (3.0”) Copper Voice Coil.
The VX-400 high frequency unit is Dynamic Horn, Ø44.45nn (1.75”) Voice Coil.
The VX-400 spl at (1w/1m) is 98dB.
