Ahuja
VX-200
- Power
- 200 WATTS
- Series
- VX Series
- Category
- Speakers
- Category
- Passive Speakers
The Ahuja VX-200 is a 200W moulded cabinet speaker system with 10" LF woofer and dynamic horn. It has a rugged and portable bass reflex cabinet moulded with a special polypropylene plastic material.
It has special cabinet profile allows functional flexibility in various professional audio applications such as stage monitors, live sound reinforcement and installed sound systems.
Features
- Compact & portable 200W, 2-Way PA speaker system comprises of a high performance 25.4cm (10") LF speaker and a reliable HF driver. Ideal for use in a wide variety of speech & music applications.
- Rugged & portable bass reflex cabinet moulded with a special polypropylene plastic material.
- Built with a 25.4cm (10") 200W reliable & efficient LF speaker.
- High performance HF driver made with a 2.54cm (1.0") voice coil & titanium diaphragm.
- Equipped with a professional passive crossover network using low resistance inductors & high quality metallised polyester capacitors.
- Special cabinet profile allows functional flexibility in various professional audio applications such as stage monitors, live sound reinforcement and installed sound systems.
- A pole socket is provided at the bottom for easy stand mounting as well as wall mounting.
- Three integrated M8 flying points on top side and right side of the cabinet enable vertical and horizontal suspension applications.
Specifications, Q&A and videos
| Power Rating | 200W RMS |
|---|---|
| Configuration | Two Way |
| Frequency Response | 65-18,000Hz |
| Low Frequency Speaker | 1 x 254mm (10"), Ø50.8mm (2.0") CCAW Voice Coil |
| High Frequency Unit | Dynamic Horn, Ø25.4mm (1.0") Voice Coil |
| SPL at (1W/1m) | 94dB |
| MAX. Rated SPL | 117dB |
| Nominal Impedance | 8Ω |
| Port | Free Flow Flared |
| Input Connectors | 6.35mm (1/4") Phone Jack + Push Terminals |
| Dimensions | W325 × H485 × D255 mm |
| Weight | 9.70kg |
The VX-200 is an Ahuja moulded cabinet speaker system in the VX Series. The Ahuja VX-200 is a 200W moulded cabinet speaker system with 10" LF woofer and dynamic horn. Authorized Ahuja dealer for Maharashtra and Goa — enquire at Mansukhlal Sales Corporation for specification and quotes.
Compact & portable 200W, 2-Way PA speaker system comprises of a high performance 25.4cm (10") LF speaker and a reliable HF driver. Ideal for use in a wide variety of speech & music applications; Rugged & portable bass reflex cabinet moulded with a special polypropylene plastic material; Built with a 25.4cm (10") 200W reliable & efficient LF speaker; High performance HF driver made with a 2.54cm (1.0") voice coil & titanium diaphragm; Equipped with a professional passive crossover network using low resistance inductors & high quality metallised polyester capacitors; Special cabinet profile allows functional flexibility in various professional audio applications such as stage monitors, live sound reinforcement and installed sound systems.
The VX-200 configuration is Two Way.
The VX-200 frequency response is 65-18,000Hz.
The VX-200 low frequency speaker is 1 x 254mm (10"), Ø50.8mm (2.0") CCAW Voice Coil.
The VX-200 high frequency unit is Dynamic Horn, Ø25.4mm (1.0") Voice Coil.
The VX-200 spl at (1w/1m) is 94dB.
