SM Professional
SWF 1580
- Power
- 1600 WATTS
- Series
- SWF Series
- Category
- Transducers
- Category
- Speaker Components
The S-Series is our most comprehensive range of high-performance transducers designed to deliver powerful sound reproduction, suit a wide variety of enclosure designs, and perform reliably for years without losing their sonic qualities.
Features
- Assembled using high-quality Ferrite magnets, tightly-wound voice coils, and responsive paper cones
- Ventilated voice coil gap to reduce power compression, improve conversion efficiency, and superior cooling.
- Heavy-duty die-cast frame with a wide flange for increased rigidity.
- Engineered to suit a wide variety of enclosure designs to deliver high power, clarity, and punch.
Specifications, Q&A and videos
| Series | S Series |
|---|---|
| Product Type | Woofer |
| Power Output (RMS / Peak) Watts | 800 / 1600 |
| Frequency Range (Hz) | 40-5000 |
| Impedance | 8 |
| Sensitivity (1w @ 1m) dB | 97 |
| Nominal Diameter (mm/inch) | 380/15 |
| Voice Coil Diameter (mm/Inch) | 100 / 4 |
| Voice Coil Material | Copper |
| Kind of Layer | Inside / Outside |
| Basket | Die-cast |
| Net Weight (Kg) | 12.5 |
The SWF 1580 is an SM Professional PA product in the SWF Series rated 1600 WATTS. The S-Series is our most comprehensive range of high-performance transducers designed to deliver powerful sound reproduction, suit a wide variety of enclosure designs, and perform. Authorized SM Professional dealer for Maharashtra and Goa — enquire at Mansukhlal Sales Corporation for specification and quotes.
Assembled using high-quality Ferrite magnets, tightly-wound voice coils, and responsive paper cones; Ventilated voice coil gap to reduce power compression, improve conversion efficiency, and superior cooling; Heavy-duty die-cast frame with a wide flange for increased rigidity; Engineered to suit a wide variety of enclosure designs to deliver high power, clarity, and punch.
The SWF 1580 product type is Woofer.
The SWF 1580 power output (rms / peak) watts is 800 / 1600.
The SWF 1580 frequency range (hz) is 40-5000.
The SWF 1580 impedance is 8.
The SWF 1580 sensitivity (1w @ 1m) db is 97.
