SM Professional
DJA 12000
- Power
- 13600 WATTS
- Channels
- 2 Channels
- Series
- DJA Series
- Category
- Power Amplifiers
- Category
- 2 Channel Power Amplifiers
The SM Professional DJA 12000 is a high output stereo power amplifier.
Rated to deliver 2 x 6000W at 2Ω, 2 x 4000W at 4Ω and 2 x 2500W at 8Ω, the amplifier easily drives high wattage loudspeakers and subwoofers in a wide variety of live, touring, DJ and install applications.
Features
- Rugged and reliable professional stereo power amplifier.
- High-current toroidal transformers with high-endurance cores for superior transient response.
- Ultra-functional EQ Processing, Low Cut, and Subwoofer with crossover selection options.
- 3 switchable operational modes: stereo, parallel, and bridge.
- Intelligent cooling and heat dissipation using large low-noise variable speed fans.
- LED indicators on the front panel for power, signal, clip, bass boost and protect modes.
- Mains voltage operation 240V AC as well as low voltage operation at 150V AC.
- Audio-grade balanced XLR and ¼” jack input connectors.
Specifications, Q&A and videos
| 2 Ω (True RMS), 20Hz-20kHz, 1% THD | 2 x 6000 W |
|---|---|
| 2 Ω (EIA), 1kHz, 1%THD | 2 x 6800 W |
| 4 Ω (True RMS), 20Hz-20kHz, 1% THD | 2 x 4000 W |
| 4 Ω (EIA), 1kHz, 1%THD | 2 x 5300 W |
| 8 Ω (True RMS), 20Hz-20kHz, 1% THD | 2 x 2500 W |
| 8 Ω (EIA), 1kHz, 1% THD | 2 x 3300 W |
| 4 Ω (True RMS), 20Hz-20kHz,1% THD | 2 x 12000 W |
| 4 Ω (EIA), 1kHz , 1% THD | 2 x 13600 W |
| 8 Ω (True RMS), 20Hz-20kHz,1% THD | 2 x 8000 W |
| Damping Factor (8 Ω) | >600:1 |
| Frequency Response | 20Hz-20kHz (-3dB) |
| Protection | Temperature, DC short circuit, Soft-Start |
| Input Connector (Per Channel) | XLR |
| Output Connector (Per Channel) | Speakon and Binding Posts |
| Dimensions (W x D x H) mm | 482 x 650 x 135 (3U) |
| Net Weight (Kg) | 48 |
The DJA 12000 is an SM Professional high output stereo power amplifier in the DJA Series rated 13600 WATTS. Authorized SM Professional dealer for Maharashtra and Goa — enquire at Mansukhlal Sales Corporation for specification and quotes.
Rugged and reliable professional stereo power amplifier; High-current toroidal transformers with high-endurance cores for superior transient response; Ultra-functional EQ Processing, Low Cut, and Subwoofer with crossover selection options; 3 switchable operational modes: stereo, parallel, and bridge; Intelligent cooling and heat dissipation using large low-noise variable speed fans; LED indicators on the front panel for power, signal, clip, bass boost and protect modes.
The DJA 12000 2 ω (true rms), 20hz-20khz, 1% thd is 2 x 6000 W.
The DJA 12000 2 ω (eia), 1khz, 1%thd is 2 x 6800 W.
The DJA 12000 4 ω (true rms), 20hz-20khz, 1% thd is 2 x 4000 W.
The DJA 12000 4 ω (eia), 1khz, 1%thd is 2 x 5300 W.
The DJA 12000 8 ω (true rms), 20hz-20khz, 1% thd is 2 x 2500 W.
