SM Professional
ARC 22
- Power
- 20 WATTS
- Series
- ARC Series
- Category
- Speakers
- Category
- Wall Speakers
The ARC series range of installation speakers have been designed for every architectural aesthetic, structural & performance requirement.
The series is housed in compact forms that fit into tight spaces, corners & all the variables that contractors throw at us!
Features
- Wall mount 20W installation speaker.
- Compact, versatile & weather resistant hi-fidelity systems.
- High quality ABS enclosure.
- Clear sound reproduction.
- Great sensitivity, dispersion & wide frequency range.
- Ergonomically designed to integrate in any architectural environments.
- Convenient mounting accessories provided.
Specifications, Q&A and videos
| Series | ARC Series |
|---|---|
| Speaker Type | Wall Mount |
| Speaker Units | 4" Coaxial |
| Rated Power | 20W |
| Power Tap Selection, Switch | 10W / 20W / 16 Ω |
| Frequency Response | 95Hz-20KHz |
| Input Voltage (Max) | 100V |
| Sensitivity | 85 ±3dB (1W, 1M) |
| Cabinet Material | ABS |
| Dimensions ( WxDxH )mm | 128 x 128 x 131 |
| Net Weight | 1.35 |
| Colors available | Black |
The ARC 22 is an SM Professional Installation loudspeakers and zone system in the ARC Series rated 20 WATTS. The ARC series range of installation speakers have been designed for every architectural aesthetic, structural & performance requirement. Authorized SM Professional dealer for Maharashtra and Goa — enquire at Mansukhlal Sales Corporation for specification and quotes.
Wall mount 20W installation speaker; Compact, versatile & weather resistant hi-fidelity systems; High quality ABS enclosure; Clear sound reproduction; Great sensitivity, dispersion & wide frequency range; Ergonomically designed to integrate in any architectural environments.
The ARC 22 speaker type is Wall Mount.
The ARC 22 speaker units is 4" Coaxial.
The ARC 22 power tap selection, switch is 10W / 20W / 16 Ω.
The ARC 22 frequency response is 95Hz-20KHz.
The ARC 22 input voltage (max) is 100V.
